The Skymach HMC800S CNC Horizontal Machining Center is a high-productivity multi-axis machining center engineered for continuous unmanned processing of complex gearbox cases, automotive cylinder blocks, pump bodies, industrial hydraulic manifolds, and large aerospace structural frames. Equipped with a twin automatic exchange pallet system (2 Pallets: 800 x 800 mm (Dual Pallets)) and a high-precision 1° indexing B-axis rotary table, the HMC800S enables 4-face machining in a single clamping while loading workpieces on the external station.
Comprehensive Machining Capabilities
- Multi-Sided Prismatic Part Machining: Complete milling, precision boring, deep hole drilling, and rigid tapping on 4 sides in one setup without repositioning.
- Continuous High-Duty Production: Twin pallet changer rotates in seconds, eliminating part setup downtime and maximizing spindle utilization.
- Heavy Metal Removal & Fine Boring: High-rigidity BT50/Φ190 spindle with 15/18.5 kW drive effortlessly handles tough cast irons, ductile iron housings, and forged steels.
Key Engineering Highlights
- Heavy Monolithic Casting Bed: T-shaped structural cast bed provides outstanding dynamic stiffness, thermal stability, and natural vibration absorption.
- High-Precision Curvic Coupling Indexing: 1° x 360 mechanical indexing with 10 arcsec positioning accuracy guarantees repeatable angular alignment under heavy cutting.
- Fast Cam-Driven ATC: 30-tool disc arm tool magazine provides fast 3-second tool changes for tooling up to 18 kg and 400 mm in length.
Technical Parameters
| Model | HMC800S |
|---|---|
| Pallet Dimensions / Quantity | 800 x 800 mm (Dual Pallets) (2 Pallets) |
| X Axis Travel (Table Left-Right) | 1,300 mm |
| Y Axis Travel (Spindle Up-Down) | 1,000 mm |
| Z Axis Travel (Column / Table In-Out) | 1,000 mm |
| Spindle Center to Pallet Surface | 150 - 1,150 mm |
| Spindle Nose to Pallet Center | 200 - 1,200 mm |
| Max. Pallet Load Capacity | 1,500 kg / pallet |
| T-Slot Specification | 5-22 x 125 mm |
| B-Axis Rotary Table Indexing | 1° x 360 Positions (Optional 0.001°) |
| B-Axis Table Max. Speed | 10 RPM |
| Spindle Taper & Diameter | BT50 / Φ190 mm |
| Spindle Speed | 6,000 RPM |
| Main Motor Power | 15 / 18.5 kW |
| Rapid Traverse (X/Y/Z) | 24 / 20 / 24 m/min |
| Cutting Feed Speed | 1 - 10,000 mm/min |
| Tool Magazine Capacity | 30 Tools (Arm Type) |
| Tool Change Time (Tool-to-Tool) | 3.0 sec |
| Positioning Accuracy (X/Y/Z) | 0.012 mm |
| Repeatability (X/Y/Z) | 0.008 mm |
| B-Axis Positioning / Repeat Accuracy | 10 arcsec / 5 arcsec |
| Machine Dimensions (L x W x H) | 6600 x 4300 x 3300 mm |
| Machine Weight | 20,000 kg (20.0 t) |
Frequently Asked Questions
What is the warranty period for your machines?
We offer a standard 12-month warranty on all our CNC machines, covering the spindle assembly, ball screws, linear guides, CNC controller, and servo drive motors. Extended warranties and customized service plans are available upon request.
Do you provide overseas installation and training?
Yes. Our engineers are available for overseas dispatch to assist with machine installation, commissioning, and comprehensive operator training at your facility. Every machine also ships with English manuals, circuit diagrams, and video setup guides.
What is the typical lead time for an order?
Standard catalog machines ship within 30 days. Custom configurations — such as oversized spindle bores, extended bed lengths, or integrated 4th-axis rotary tables — typically ship within 60 days.
How do you handle spare parts requests?
We maintain a comprehensive inventory of standard spare parts. Genuine replacement components are dispatched via international express (DHL/FedEx) within 48 hours, ensuring minimal downtime for your production line.
